Brand: Supermicro
Features:
- Intel Xeon E-2300 Processor, 10th Generation Intel Pentium Processor, Single Socket LGA-1200 (Socket H5) supported, CPU supports Up to 95W TDP
- Intel C256
- Up to 128GB ECC UDIMM, DDR4-3200MHz, in 4 DIMM slots
- Dual LAN with Intel Ethernet Controller I210
- Intel C256 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
Binding: Personal Computers
Release Date: 20-12-2022
model number: MBD-X12STH-F-O
Part Number: MBD-X12STH-F-O
Details: Intel® Xeon® E-2300 Processor, 10th Generation Intel® Pentium® Processor, Single Socket LGA-1200 (Socket H5) supported, CPU supports Up to 95W TDP Intel® C256 Up to 128GB ECC UDIMM, DDR4-3200MHz, in 4 DIMM slots 1 PCI-E 4.0 x16 1 PCI-E 4.0 x4 (in x8 slot) 1 PCI-E 3.0 x4 (in x8 slot) M.2 Interface: PCI-E 3.0 x4 M.2 Form Factor: 2280, 22110 M.2 Key: M-Key Dual LAN with Intel® Ethernet Controller I210 Intel® C256 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10 2 SuperDOM with built-in power I/O: 1 VGA, 2 COM, 1 TPM header 5x USB 3.2 Gen1 (2 rear, 1 Type-A, 2 via header), 6x USB 2.0 (2 rear, 4 via headers) Gen12 iGPU support
EAN: 0672042472796
Package Dimensions: 11.2 x 10.9 x 2.2 inches
Languages: English
