Brainboxes Device Server - 10Mb LAN, 100Mb LAN, RS-232, RS-422, RS-485 (ES-511) ^Sale

Brand: Brainboxes

Color: Yellow

Features:

• Brainboxes state of the art auto gating for trouble free RS485 half duplex flow control
• 10/100 Base TX Ethernet port
• User friendly interface, simple to use, powerful in operation
• Web configuration and RFC2217 compliant interface for non-Windows users
• IP-30 rated non-conducting polyamide enclosure

Binding: Personal Computers

Release Date: 15-11-2018

model number: ES-511

Part Number: ES-511

Details: Ethernet to serial device with 1-port software selectable as RS232, RS422/485 full duplex or RS422 half duplex. ES-511 has removable screw terminals blocks for easy wiring, a slim 'end on' case and integral DIN rail mount. Industrial Ethernet to Serial has an operating temperature range of -30 to +80 degrees Celsius and with +5 V DC to +30 V DC dual input reverse polarity protected power supply making it perfect for industrial applications. Data transfer rates up to 1,000,000 baud, coupled with 1 Mbit/s line drivers deliver uncompromising performance. Industrial ES range provides simple instant networked serial ports in demanding environments. Serial port tunneling allows serial cable replacement over any distance, no software required.

EAN: 8373240026072

Package Dimensions: 6.2 x 5.3 x 1.8 inches
