Brand: Syba
Features:
- MCS9922 Chipset
- Compatible with Industrial Standard 16C550 UART. On Chip 256-byte Depth FIFO in Transmit.
- Transfer data rates up to 250Kbps on each port. Supports hardware and software flow control. Supports 5, 6, 7, 8-bit Serial format
- Fully compliant with PCI-Express base Specification Revision 1. 0a
- Single-lane (x1) PCI-Express with throughput up to 2. 5Gbps
- Form Factor: Low profile
Binding: Personal Computers
Release Date: 01-05-2019
model number: SD-PEX15021
Part Number: SD-PEX15021
Details: MCS9922 is a single lane multifunction PCI express to I/O controller. It supports two serial ports and eight GPIO's. MCS9922 also provides an option for peripheral expansion through proprietary Cascade interface. The generic cascade interface allows interconnecting with similar chips like MCS9900 to expand the peripheral ports.The serial ports are compatible with RS232, RS422 & RS485 standards and supports throughput from 50bps to 16Mbps. All the GPIO pins are programmable and can be used as Input or Output. An I C interface is provided to configure MCS9922 device options through an external EEPROM.
EAN: 0168141446214
Package Dimensions: 6.9 x 5.6 x 1.5 inches
