Key Features C 12th Generation Intel Core i9 / i7 / i5 / i3 / Pentium / Celeron Processor, Single Socket LGA-1700 supported, CPU TDP supports Up to 125W TDP Intel R680E Up to 128GB Unbuffered ECC / non-ECC UDIMM, DDR5-4400MHz, in 4 DIMM slots 1 PCI-E 5.0 x16 slot, 2 PCI-E 4.0 x4 slots, 1 PCI-E 4.0 x4 OCulink port M.2 Interface: 1 PCI-E 4.0 x4 M.2 Form Factor: 2280 / 22110 M.2 Key: M-Key Dual 2.5 Gigabit LAN with Intel Ethernet i225LM LAN controller AMT / vPro 1 VGA port, 2 DP++ ports, 1 HDMI 2.0b port, 1 DVI - D port Intel R680E Controller for 4 SATA3 (6 Gbps) ports RAID 0,1,5,10 Supports 12V DC power input Onboard TPM2.0Physical Stats C Form FactorC Micro-ATXProcessorC CPUC 12th Generation Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron Processor Single Socket LGA-1700 supported CoreC Up to 16 coresSystem MemoryC Memory CapacityC 4 DIMM slots Up to 128GB ECC / non-ECC UDIMM, DDR5-4400MHz Supports up to 128GB of DDR5 UDIMM with speeds of up to 4400MT / s with one DIMM, or 4000MT / s with two DIMM single rank, or 3600MT / s with two DIMM dual rank in four memory slots Memory TypeC 4400 / 4000 / 3600MHz DIMM SizesC 4GB, 8GB, 16GB, 32GB Memory VoltageC 1.1V Error DetectionC Corrects single-bit errors Detects double-bit errors (using ECC memory)On-Board DevicesC ChipsetC Intel R680E SATAC Intel R680E controller for 4 SATA3 (6 Gbps) ports RAID 0,1,5,10 AudioC ALC 888S HD Audio Network ControllersC Dual LAN with Intel Ethernet i225LMInput / OutputC SATAC 4 SATA3 (6Gbps) port(s) USBC 2 USB 2 port(s) (2 via header) 6 USB 3.1 Gen2 port(s) (2 via header 4 rear type A) 2 USB 3.1 Gen1 port(s) (2 via header) Video OutputC 1 VGA port(s), 1 DVI - D port(s), 1 HDMI 2.0b port(s), 2 DP (DisplayPort) port(s) Serial PortC 4 COM Port(s) (2 header RS232 / 422 / 485 2 header RS232) TPMC TPM Header andChip bothExpansion SlotsC PCI-EC 1 PCI-E 5.0 x16, 2 PCI-E 4.0 x4 (in x8 slot) M.2C M.2 Inter...
